Follow the exact formula and code clause.
Inspect section properties, effective widths, substrate roughness multipliers (CSP 1–5), and chemical compatibility guardrails (EN 12004) right beside the output.
BUILDING SYSTEMS · QUANTITIES · STUDIO BIM
Every layer.
One living
record.
Bridge the gap between structural partition mechanics, 10-system room finish schedules, package takeoffs, and coordinated project records. Designed for teams that refuse to lose engineering context between spreadsheets and site delivery.
MODE 01 / EXPLODED ASSEMBLY CUTAWAY
AXONOMETRIC 30°/30° ↗
01
Clarity, layer by layer.
Inspect board combinations, cold-formed steel stud inertia, and composite deflection limits with every assumption in view.
N ↑
ILLUSTRATIVE WORKFLOW MODEL · NOT A CERTIFIED DRAWING
Assembly view: keep materials and design inputs in view.
Less disconnected guesswork.
One verifiable engineering thread.
Structural & Acoustic CFS
10-System Turnkey Finishes
Dual-Channel BOQ & Packaging
Studio Hierarchy & IFC4
01 / PLATFORM ARCHITECTURE
Engineering depth.
Architectural composure.
A partition calculation shouldn’t live in one file, room finishes in a second spreadsheet, and procurement packages in a third. BinaLink connects every stage on one shared geometric truth.
01 / STRUCTURAL & ENVELOPE MECHANICS
AISI S100 · EN 1993-1-3 · TBDY 2018
Design the assembly with visible mechanics.
Analyze cold-formed steel partitions, suspended ceilings, floors, and façades. Inspect effective section modulus, composite sheathing action, deflection limits (L/240 to L/500), and seismic checks without hidden black-box macros.
- Single & boxed C-stud limiting-height optimization
- Acoustic mass-spring-mass & thermal U-value evaluation
- Opening lintels, jamb studs & seismic head details
02 / 10-SYSTEM ROOM ENGINE
From bare shell to turnkey room finishes.
Compute 10 core interior & envelope systems from four room dimensions—automatically including often-forgotten hidden accessories like seismic tie anchors, corner beads, chamfer tapes, and primer pairings.
Explore quantity & package logic
03 / STUDIO SPATIAL TREE
Keep every room and revision in context.
Organize buildings, floors, rooms, and elements in Studio. When an input or opening changes, BinaLink keeps revision history, supporting evidence, and review status attached to the exact room node.
See Studio project coordination
04 / DUAL-CHANNEL PROCUREMENT & OPEN BIM
IFC4 · BOQ SCHEDULES · HONEST PRICING SCOPE
Turn geometry into packages, tenders, and BIM deliverables.
Convert net demand into commercial purchase units (boards, stock profile lengths, bags, pails) and route materials between Factory-Direct bulk orders and Showroom/Dealer selections—while keeping unpriced items transparently flagged rather than silently guessed.
- Factory-Direct vs. Showroom/Dealer supply-chain split
- Drywall vs. Masonry dead-load & schedule comparator
- Supported IFC4 BIM exchange, CSV/XLSX BOQ & engineering dossiers
02 / INTERACTIVE ARCHITECTURAL SANDBOX
Test the geometric logic.
Right in your browser.
Adjust room dimensions or switch between Drywall and Masonry below to see how BinaLink derives net wall geometry, structural dead-load savings, and commercial package rounding in real time.
WALL SYSTEM MODE
ROOM NODE / EXECUTIVE OFFICE
Anet = Proom·H − ∑Aop
Twin-Layer CFS Drywall System (W112)
FLOOR AREA (Afloor)
27.0 m²
6.0m × 4.5m
PERIMETER (Proom)
21.0 m
19.2 m net skirting
NET WALL AREA (Awall,net)
58.9 m²
−4.1 m² openings deducted
ENVELOPE MASS (DEAD LOAD)
2.83 t
~76% lighter than masonry
LIVE PACKAGE & ACCESSORY TAKEOFF PREVIEW
FACTORY + DEALER ROUTING
| Component / Hidden Accessory | Engineering Basis | Gross Demand | Commercial Packages |
|---|---|---|---|
| Gypsum Boards (2×2 Faces) | Anet × 4 layers (+5% waste) | 247.4 m² | 83 Sheets (3.0 m²) |
| CFS C-Studs & U-Tracks | 600mm c/c + Opening Jambs | 154.0 m | 52 Lengths (3.0 m) |
| Mineral Wool Acoustic Core | 50mm Cavity · 50 kg/m³ | 60.7 m² | 9 Packs (7.2 m²) |
| Joint Compound, Tape & Acoustic Sealant | Q2/Q3 Finish + Perimeter Isolation | 44.2 kg + 42 m | 2 Bags + 2 Rolls |
03 / ROLE-BASED WORKSPACES
Five focused entry points.
One shared project truth.
Whether you manufacture drywall profiles, coordinate multi-storey hospital rooms in a design office, or price turnkey packages on site, BinaLink adapts its workspace and permissions to your role.
WORKSPACE 01 / FROM PRODUCT CATALOGUE TO PROJECT DEMAND
Make your systems easier to specify and quantify.
Give technical sales and specification teams two dedicated tracks—Drywall & Profiles and Construction Materials & Finishes—so every system recommendation comes with traceable calculations and package schedules.
- Compare stud profiles, board configurations, and limiting heights side by side
- Generate instant package takeoffs (sheets, bags, pails, stock coils) from room geometry
- Manage role-based product libraries, technical data sheets, and regional price books
04 / THE CONNECTED WORKFLOW
One decision informs
the very next step.
Start with a single partition check or a multi-level building in Studio. As the work moves from engineering to procurement and BIM, the inputs and reasoning travel with it.
Assembly design & structural check
INPUTS & METHOD IN VIEW
LAYERED CFS PARTITION
Selected system Twin-Board C75 Partition
Design inputs Span 3.0m · 0.24 kPa · L/360
Result context AISI S100 LRFD + Scope
See the inputs behind every result.
Explore an assembly with its geometry, profile properties, and declared load assumptions. Keep the calculation’s exact engineering scope in view.
05 / GLASS-BOX ENGINEERING
Don’t just get
a number.
Own the reasoning.
In construction engineering, an unverified number is a liability. BinaLink is architected around glass-box transparency—separating deterministic geometry, structural checks, laboratory test evidence, and commercial quotations so your team never mistakes an assumption for an approval.
LEGACY FRAGMENTATION
- Locked spreadsheet cells with hidden assumptions
- Manual copy-pasting from CAD to BOQ tables
- Missing unit prices silently zeroed or guessed
THE BINALINK STANDARD
- Every formula, load & boundary condition visible
- One room geometry drives 10 finish systems & BIM
- Explicit incomplete-pricing flags until quotes are entered
Keep the thread from concept to site.
Connect standalone calculations with Studio’s building-level-room tree, revision checkpoints, uploaded TDS/DoP documents, and role-based access controls.
See clearly what still requires sign-off.
BinaLink distinguishes numerical calculations, laboratory fire/acoustic test evidence, and professional engineering approval—giving reviewers total clarity.
06 / COMMON QUESTIONS
Technical clarity,
up front.
Have a specific question about your product catalogue, design office workflow, or VPS deployment?
Ask our team directly
Who is BinaLink designed for?
BinaLink serves building-material manufacturers and distributors, architectural and structural design offices, contractors, and estimators. Role-based workspaces ensure each user sees only the pages and tools relevant to their discipline.
Can I run a quick single calculation without creating a full building project?
Yes. The Single Design Workbench provides five dedicated discipline tabs—Drywall & Partitions, Suspended Ceilings, Floors & Screeds, Materials & Room Finishes, and Façades & Envelope—for immediate standalone analysis that can be attached to a Studio project later.
What systems are covered in the Turnkey Room Finish Engine?
From four room dimensions (Length, Width, Height, and Openings), the engine computes 10 systems: Masonry Walls, Interior/Exterior Plasters, Screeds, Waterproofing, Ceramic/Stone Tiling, Drywall Partitions, Suspended Ceilings, Paint & Primers, Laminate/Parquet Flooring, and Doors/Windows—including hidden accessories and a Drywall vs. Masonry dead-load comparator.
Can we use our own product catalogues and quotation prices?
Yes. Authorized roles can manage steel profiles, board libraries, construction chemicals, and regional price books. Missing rates remain explicitly flagged as incomplete pricing rather than being silently invented.
How are calculations, test ratings, and approvals handled?
Calculation outputs, laboratory fire/acoustic test evidence, and responsible engineer approvals are treated as distinct facts. BinaLink preserves the scope and evidence trail so teams can review and approve work responsibly.
